CP Series Plastic with LED 100-230V AC/DC Blue 22 mm Pilot
IEC 60204-1 assigns blue a specific job: signalling that the operator must take a mandatory action, distinct from the emergency/abnormal/normal roles given to red, yellow, and green. The CP0M0XM is a mains-voltage lamp built for exactly that duty — resetting after a fault, confirming a required setup step — wiring straight into 100-230V AC circuits without a step-down transformer. It's rated for 10,000 hours of electrical life, priced below premium-brand equivalents, and held in UK stock for fast dispatch.
Technical Details
Frequently Asked Questions
Can I wire this directly to mains voltage?
Yes — this version runs on 100-230V AC directly, so no step-down transformer is needed if your panel circuit is already mains-fed.
What's the difference between this and the 12-30V version?
This is the mains-voltage variant, suited to circuits already switching 100-230V AC. If your control circuit runs on 24V DC or similar low voltage, use the CP070XM (12-30V) version instead.
Is this suitable for washdown or outdoor panel mounting?
Yes — IP65 rated, protected against dust ingress and low-pressure water jets, suitable for washdown areas.
What does blue indicate under IEC 60204-1?
IEC 60204-1 Clause 10.3 assigns blue to "mandatory" — meaning it flags a condition where the operator needs to take a specific required action, such as resetting a fault or completing a setup step. That's a distinct role from red's emergency signal or yellow's abnormal-condition warning, and it's why blue is the standard's recommended choice for reset indication rather than an arbitrary extra colour.
Industry Applications
- Manufacturing control panels — mandatory-action indication (reset, setup confirmation) distinct from red/yellow/green states
- Process equipment — flagging a required operator step on mains-switched HMIs
- Packaging & conveyor systems — reset-required signalling alongside primary run/fault lamps
