MB Series Plastic with LED 12V AC/DC 22 mm Buzzer
EMAS indicators are simple to install and connect. They can be expected to withstand production environments, offering branded reliability at a competitive price.
This is a one piece device suitable for a combined audible and visual alarm.
Operates on 12V and can be used for control systems, off-grid and automotive applications.
Annunciator, Indicator, Alarm for BMS, Control Panel, Process, PLC.
Bulb Type
Led
Operating Current
18 mA
Operational Frequency
50 Hz
Operational Voltage
12V AC/DC
Product
Buzzer
Illumination
with LED
Dia
22 mm
Volume
90 dB
Power Consumption
0.3W
Insulation Voltage (Ui)
250 V
Operating Temperature
-15 / + 70 °C
Protection Degree
IP50
Cable Section
1.5-2.5 mm²
Screw Torque
1,5 Nm
Serial
MB Series Plastic
Electrical Life (Min Hour)
10000
