CP Series Plastic 1NO Spring Flush Black Vertical (Arrow) Sign Marked 22 mm Control Unit
Momentary pushbutton marked with a white arrow (DOWN) on a black background.
Suitable for lift, crane and hoist applications. Widely used on roller shutter doors.
Print
Vertical (Arrow) Sign Marked
Product
Control Unit
Model
Spring
Type
Flush
Contact
1NO
Color
Black
Dia
22 mm
Current (Ie)
4 A (230V AC)
Usage Category
AC 15
Mechanical Life (Min Qty)
500000
Electrical Life (Min Qty)
100000
Operating Frequency (On-Off/Hour)
Mech. 3000 Elec. 1200
Insulation Voltage (Ui)
300V
Impulse Withstand Voltage (Uimp)
2.5 kV
Dielectric Strength (Body-Contact)
2.500V AC
Dielectric Strength (Contact-Contact)
1.500V AC
Isolation Resistance
10 MΩ min. (500V DC)
Operating Temperature
-15 / + 65 °C
Pollution Degree
3
Protection Degree
IP65
Contact Material
AgNi
Cable Section
1.5-2.5 mm2
Screw Torque
1,5 Nm
Short Circuit Breaking Capacity (Ics)
1 kA
Serial
CP Series Plastic
